1080p HD over CAT5e/6/7 Ethernet Extender
Extend HDMI and IR signals over CAT5e/6/7 up to 164ft/50m. EDID management for seamless integration. [EXHD50E-H]
• Extends 1080p resolution up to 164ft/50m over Cat5e/6/7 Ethernet
• EDID selection from local or remote display
• Supports HDMI loop out function at Transmitter side
• Supports High Definition resolutions up to 1080P@60Hz
• Supports unidirectional wideband IR control from display to source
• Supports Power over Cable (POC) from Transmitter to Receiver
• Compact design for an easy and flexible installation
Technical | |
HDMI Compliance | HDMI 1.4b |
HDCP Compliance | HDCP 1.4 |
Video Bandwidth | 4.95 Gbps |
Video Resolutions | up to 1080P@60Hz |
Color Space | RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
Color Depth | 10-bit, 12-bit |
Audio Formats | PCM 2CH, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby Digital+ |
ESD Protection | Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge) |
Connections | |
Inputs |
TX: 1x HDMI Type A [19-pin female] RX: 1x RJ45 [HDMI & Propriety Data] 1x 3.5mm Stereo Mini-jack [Infrared Receiver] |
Outputs |
TX: 1x HDMI Type A [19-pin female] 1x RJ45 [HDMI & Propriety Data] 1x 3.5mm Stereo Mini-jack [Infrared Emitter]RX: 1x HDMI Type A [19-pin female] |
Mechanical | |
Housing | Metal Enclosure |
Dimensions | TX/RX:60mm [W] x 60mm [D] x 15mm [H] |
Net Weight | TX/RX: 300g |
Power Supply | Input: AC100 - 240V 50/60Hz Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified) |
Power Consumption (Max) | TX: 1.5W RX: 1W |
Operation Temperature | 32 - 104°F / 0 - 40°C |
Storage temperature | -4 - 140°F / -20 - 60°C |
Relative Humidity | 20 - 90% RH (no condensation) |
