4K 1x16 HDMI Splitter
Click to enlarge
High quality, small form factor 4K HDMI splitter. Distribute one 4K signal to up to 16 displays using HDMI leads up to 15m long. [SP4K116H]
A robust and high quality sixteen way HDMI splitter for distributing video resolutions up to 4K UHD from a single HDMI source to sixteen displays via HDMI leads that can be up to 15m in length. Simple plug and play installation. Small form factor ideal for shelf mounting in small spaces.
Technical Specifications
| HDMI Compliance | HDMI 2.0b |
| HDCP Compliance | HDCP 2.2 |
| Video Bandwidth | 18Gbps |
| Video Resolution |
Up to 4k2k@50/60Hz 4:4:4 |
| Colour Depth | 8-bit,10-bit,12-bit(1080p@60Hz) 8-bit (4K2K@60Hz YUV4:4:4) 8-bit,10-bit,12-bit(4K2K@60Hz YCbCr 4:2:2/4:2:0) |
| Colour Space | RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2/4:2:0 |
| HDR | Support HDR, HDR10, HDR10+, HLG, Dolby vision |
| HDMI Audio Formats |
PCM2.0/5.1/7.1CH, Dolby 5.1, DTS5.1, Dolby-TrueHD, DTS-HD |
| Power Supply | 12V / 2.5A DC |
| Power Consumption | 6.15W |
| Dimensions | 300mm (W) × 100mm (D) × 28mm (H) |
| Weight | 900 |
